MXi.12FX
12 Kanal Deck Mixer
4 Mikrofon- Line, 4 Stereo Input , 1 RCA, 3 band EQ, Phantom, Kulaklık Çıkışı, Kontrol Odası Çıkışı (Mix Operatörü),
Boyutlar ve Ağırlık : 41 x 272 x 259 mm (1.6" x 10.7" x 10.2")
1.4 Kg (3.1 lb)/1.8 Kg (3.9 lb)

MXi.1222CFX
12 Kanal Deck Mixer
6 Mikrofon- Line, 2 Stereo Input , 2 RCA,
3 band EQ, Phantom,
Kulaklık Çıkışı,
Kontrol Odası Çıkışı (Mix Operatörü),
2 Group Out / mute
USB Input
Built in 24-bit DSP effect wilt 100 presets
Assembled MP3 Player
Low Cut For each MIC Input
4 COMPRESSORS control and 6/8 ınsert I/O

MXi.1422CFX
14 Kanal Deck Mixer
8 Mikrofon- Line, 2 Stereo Input , 2 RCA,
3 band EQ, Phantom,
Kulaklık Çıkışı,
Kontrol Odası Çıkışı (Mix Operatörü),
2 Group Out / mute
USB Input
Built in 24-bit DSP effect wilt 100 presets
Assembled MP3 Player
Low Cut For each MIC Input
4 COMPRESSORS control and 6/8 ınsert I/O

MXi.2422CFX
24 Kanal Deck Mixer
16 Mikrofon- Line, 2 Stereo Input , 2 RCA,
3 band EQ, Phantom,
Kulaklık Çıkışı,
Kontrol Odası Çıkışı (Mix Operatörü),
2 Group Out / mute
USB Input
Built in 24-bit DSP effect wilt 100 presets
Assembled MP3 Player
Low Cut For each MIC Input
16 COMPRESSORS control and 6/8 ınsert I/O

MXi.1622CFX
24 Kanal Deck Mixer
16 Mikrofon- Line, 2 Stereo Input , 2 RCA,
3 band EQ, Phantom,
Kulaklık Çıkışı,
Kontrol Odası Çıkışı (Mix Operatörü),
2 Group Out / mute
USB Input
Built in 24-bit DSP effect wilt 100 presets
Assembled MP3 Player
Low Cut For each MIC Input
16 COMPRESSORS control and 6/8 ınsert I/O

TMA 54ZBT
5 Kanal 4 Zone 100V Power Mixer Amfi
4 x 120W 100V / 8 ohm
4:Mic/Phantom:-50dBV;
1:Line: -10dBV balance
Telephone paging girişi
Her kanal için 4 Bölge seçim anahtarı , 5 Kanal Sessiz kontrol, Bluetooth bağlantı imkanı
Dimensions:(WxHxD)
483mm(W) x 133mm(H) x 395mm(D)

TPM6250 MKII
600W 2 Ohm Power Mixer Amfi
6 Mikrofon-Line, 1 adet Stereo RCA
Tüm girişler için 7 band equalizer
Built in 24-bit DSP effect wilt 100 presets
Bluetooth connectivity
410*220*274mm(16.34'*8.66'*10.79')
9.70Kg(21.38lbs)

TPM8250 MKII
600W 2 Ohm Power Mixer Amfi
8 Mikrofon-Line, 1 adet Stereo RCA
Tüm girişler için 7 band equalizer
Built in 24-bit DSP effect wilt 100 presets
Bluetooth connectivity
480*220*274mm(18.98'*8.66'*10.79')
10.80Kg(23.81lbs)

TPM 7.800+TAC-MP3-T
10 Kanal Efektli/MP3 Çalar Power Mixer
6 Mikrofon-Line, 1 adet Stereo, 1 adet Speakon+Line,
RCA, 20Hz to 220KHz, ± 3dB, 2x400 Watt/800 Watt Bridged Mod 4ohm,
Her mono kanal için 3 band EQ, 2 x 7 band Master EQ,
USB (Flash disk - MP3 için).

DR16.4
16 KANAL PROFESYONEL DIGITAL MIXER
16 Input, 10 XLR's / 3 Stereo ,
2 Main Outputs /2 Aux Outputs / 2 Control Outputs,
Buses / 2HD FX Processors / Gate / PEQ ,
Camp. / Physical metering / Software Meters ,
iPad Reote Control Easy Install Matrix.

T-2208
22 KANAL PROFESYONEL DIGITAL MIXER
22 Input, 16 XLR's / 4 Line, 2 usb / 12 Outputs
Buses / 2HD FX Processors / 32 DSP Channels
Gate / PEQ / Camp. / 6 DCA Groups
Physical metering / Software Meters / iPad Reote Control Easy Install Matrix

DM24.8
24 KANAL PROFESYONEL DIGITAL MIXER
24 Input, 24 XLR or 6.3 line / 8 XLR aux out 2 Multi-Effects Engines,
25 Digital Inserts main out and Solo Bus Out / 12 DCA Groups,
Dante or Usb / 13 Motorized Faders / Gate / PEQ,
Camp. / Physical metering / Software Meters / iPad Reote Control Easy Install Matrix

TDX 8000
* 2 x 1000 Watt Güç Amfisi
* 2000W x 2 CH , 1U and Class-D amplifier 2/4Ω (RMS)
* Frequency Response (At 10dB below Rated Output Power) 20Hz~20KHz (+0/-1dB)
* Dimension (HxWxD) 44 x 483 x 360 mm / 1.73" x 19.02" x 14.17"
* Weight 5.0 kg / 11.02 lbs

TD500.4DSP
4 x 500 Watt DSP Güç Amfisi
4 ohm 4x500W
8 ohm 4x250W
8 ohm 2x1000W
4 ohm 2x1400W
4 x 500W (8 Ohm), Frequency Response 20Hz-20Khz,
Switching Power Class D, Control Encoder,
Input 4 XLR, Dimensons 44x483x460mm, 8Kg

TRX-6000
2x1225 Watt 8 ohm, 2 x 2150 Watt) 4 ohm,
2 x 5200 Watt 2 Ohm, 4140 Watt 8 ohm köprülenmiş,
9600 Watt 4 ohm köprülenmiş Profesyonel Stereo Güç Amfisi

TDI-P1
PASİF DIRECT BOX
1/4" mono Jack(Tip Hot, Sleeve Ground) parallel link çıkışı
1/4" Jack Dengelenmemiş 50K/ Dengelenmiş 600Ohm 10Hz to 30KHz,
±1dB 127 x 76 x 45mm 0.54Kg

TAC-MP3-4 XSC
USB/MP3 Player Panel

DLM-808
Digital Ses İşlemcisi
8x8 Digital Matrix
Gate/Exp/Crossover/Peq/Delay/Compressor function
RC NET for CL4 control
DANTE optional card READY (TP T-DANTE)

DLM-408
Digital Ses İşlemcisi
4x8 Digital Matrix
Gate/Exp/Crossover/Peq/Delay/Compressor function
RC NET for CL4 control
DANTE optional card READY (TP T-DANTE)

DMX D32 USB
32 KANAL USB KAYIT MODULU

DMX LAN
LAN/ETHERNET MODULU

LINE ARRAY ASKI APARATI(APX SERİSİ İLE KULLANILIR)

8'' Aktif Hoparlör (DSP)
LF Sürücü : 8" Woofer, LF Bobin : 2.5"
HF Sürücü : 1" Compression Driver
HF Bobin : 1.75''
Güç : 2000 watts program, 4000 watts Peak
Frekans Tepkisi :60Hz - 20kHz, Maks
SPL : 125dB
Koruma Sistemi : Aşırı Isınma, Aşırı Yükleme, Dijital Limiter/Compressor
100-120VAC, 50-60Hz / 220-240VAC, 50-60Hz
Boyutlar ve Ağırlık : 322 x 328 x 319mm, 16.5 kg

12'' Aktif Subwoofer (DSP )
LF Sürücü : 12" Woofer, LF Bobin : 2.5"
Güç : 2000 watts program, 4000 watts Peak
Frekans Tepkisi : 35Hz - 200Hz
Maks SPL : 128dB
Koruma Sistemi : Aşırı Isınma, Aşırı,Yükleme, Dijital Limiter/Compressor
100-120VAC, 50-60Hz / 220-240VAC, 50-60Hz
Volume Control / Phase Switch / Power ON Yeşil LED / Clip Limiter Kırmızı LED USB PORT
Boyutlar ve Ağırlık : 439 x 417 x 512mm, 23.9 kg

Stereo Mode
8O/ 1KHz /1% THD Continuous 350W*2
4O/ 1KHz /1% THD Continuous 540W*2
2O/EIA 1KHz /1% THD Peaks 1500W*2
Bridge Mono Mode
8O/ 1KHz /1% THD Continuous 1090W
4O/ 1KHz /1% THD Peaks 3000W
Max. Continuous Voltage Swing THD=1%, 1KHz 58V
Voltage Gain,ref.1KHz 32dB
Max. Power Consumption output power @4 ohms 1600W
Dimension (cm) 61.1 x 59.4 x 18.6
Weight (kg) 20.5

8O/ 1KHz /1% THD Continuous 700W*2
4O/ 1KHz /1% THD Continuous 1200W*2
2O/EIA 1KHz /1% THD Peaks 2800W*2
Bridge Mono Mode
8O/ 1KHz /1% THD Continuous 2080W
4O/ 1KHz /1% THD Peaks 5000W
Max. Continuous Voltage Swing THD=1%, 1KHz 79V
Voltage Gain,ref.1KHz 36dB
Max. Power Consumption output power @4 ohms 2500W
Dimension (cm) 61.1 x 59.4 x 18.6
Weight (kg) 25.1

Power (Both channels driven) 360W x 4 2Ω (EIAJ) - 150W x 4 4Ω (RMS) - 90W x 4 8Ω (RMS)
Bridge Mono 720W x 2 4Ω (EIAJ) - 300W x 2 8Ω (RMS)
Input Sensitivity (Limiter Off) 0.9 - 1.1V (+0/-1dBv)
Input Impedance 20K ohms balanced or 10K ohms unbalanced
Frequency Response 20Hz~20KHz (+0/-1dB) (At 10dB below Rated Output Power)
Voltage Gain 28 (+/-0.5dB)
THD + N <0.1% (1KHz 1/8 Rated Power, A-Weighted)
S/N Ratio (Ref. 1KHz, A-Weighted) > 96dB
Crosstalk (Below Rated Power) > 70dB
Damping Factor (1KHz, 8W) > 200
Power/Output Circuity Switching Power Class-D

Power (Both channels driven)
130W x 8 / 4Ω - 70W x 8 / 8Ω
Input Sensitivity (Limiter Off)
0.9 - 1.1V (+0/-1dBv)
Input Impedance
20KΩ balanced or 10KΩ unbalanced

Potencia (Ambos canales)
130W x 8 / 4Ω - 70W x 8 / 8Ω
Sensibilidad de Entrada (Sin Limitador)
0.9 - 1.1V (+0/-1dBv)
Impedancia de Entrada
20KΩ balanceada o 10KΩ desbalanceada

Power 70V (RMS)
150W x 4 (One Channel Driven) - 135W x 4 (All Channel Driven)
Power 100V (RMS)
150W x 4 (One Channel Driven) - 135W x 4 (All Channel Driven)
Input Sensitivity (Limiter Off)
0.9 - 1.1V (+0/-1dBv)
